21000-28-05-20-018-03-02 – Bently Nevada | Probe Assemblies

Bently Nevada 21000-28-05-20-018-03-02 Probe Housing

 Key Features

• 8mm XL Probe Ready – Hazardous area approved
• 0.5m Cable – (20 inch) included
• 2″ Standoff + 1.8″ Penetration – Total 3.8″ reach
• Complete Fittings Kit – Includes adapters and seals
• Explosion Proof – CSA Type 4 certified

 Model Number Breakdown

21000 – Base Model

• 28 → 3300 XL 8mm Probe
• 05 → 0.5m Cable
• 20 → 2″ Standoff
• 018 → 1.8″ Penetration
• 03 → Full Fittings Kit
• 02 → 3/4-14 NPT Thread

 Specifications

• Total Reach: 3.8″ (96.5mm)
• Weight: 2.4 lbs (1.1 kg)
• Material: Aluminum body with 304 stainless sleeve
• Adjustment Range: ±0.5″

 Installation Notes

• Counter-bore recommended for 1-2″ penetrations
• Support required if extension >12″
• Works with 3300 XL probe series

 Package Contents

• Housing assembly
• 0.5m probe cable
• 3/4-14 NPT plug
• Reducer (3/4-14 to 1/2-14)
• Cable seal grip with grommets

 Certifications

CSA Type 4 | API 670 Compliant | Hazardous Area Approved

Download PDF file here:21000-24701-Datasheet
