21000-28-10-15-095-04-02 – Bently Nevada | New Housing Assembly

Bently Nevada 21000 Proximity Probe Housing – Explosion-Proof & API 670 Safe

Made for dangerous industrial areas, the Bently Nevada 21000 Proximity Probe Housing is safe and strong. Factory-sealed, it has an aluminum body and 304 stainless steel sleeve. Good for places needing explosion-proof tools.

Key Details

• Brand: Bently Nevada
• Model: 21000 Proximity Probe Housing Assemblies
• Material: Aluminum body + 304 stainless steel sleeve
• Weight: 1.1 kg (2.4 lb) (no extra parts)
• Size: Max (C)+(D) 17.0-32.9 in (43.18-83.5 cm)
• Temp Range: T5 (-50°C to +40°C); T4 (-50°C to +80°C)

Model Code: 21000-28-10-15-095-04-02

Each part tells a feature:

• 28: 3300 XL 8 mm probe (hazard area safe)
• 10: Probe cable: 1.0 m (39 in)
• 15: Standoff: 1.5 in (38 mm)
• 095: Probe depth: 9.5 in
• 04: One 3/4-14 NPT plug
• 02: 3/4-14 NPT thread (needed for non-00 standoffs)

How to Install

Use 3/4-14 NPT thread (code 02) if you have a non-00 standoff. Use the included sealant to fix connections.

Works With

Goes with CSA hazard area probes. CSA Type 4 certified. Follows API 670 rules for external probes.

Certifications

• RoHS 2011/65/EU
• CSA explosion-proof (North America):
  • Class I Div 1/2 (Groups C, D)
  • Class II Div 1/2 (Groups E, F, G)
  • Class III

Note: CA21000/CA24701 for North America only; others use 21000/24701.

What’s in the Box

• Dome cover (screws into housing)
• Threaded conduit ports
• Probe sleeve (length optional)
• O-rings
• Reverse mount probe
• Thread seal
• Optional conduit parts (if ordered)
• Optional standoff (if ordered)

Download PDF file here:21000-24701-Datasheet
