Bently Nevada 330903-00-02-10-01-00 3300 NSv Proximity Probe

Product Overview

The Bently Nevada 3300 NSv Proximity Probe is a durable sensor for industrial use. It resists chemicals better than older 3300 RAM models, making it ideal for process compressors. Its side-view performance also beats 3000-series 190 probes at the same target distance.

Model Code Explained

330903: Base 3300 NSv Probe (M8x1 thread, no armor)
-00: 00mm unthreaded length
-02: 20mm case length
-10: 1.0m total length (39in)
-01: Mini ClickLoc connector with protector (standard cable)
-00: No special certifications needed

Key Technical Specs

Brand: Bently Nevada
Model: 3300 NSv (Part Number: 330903-00-02-10-01-00)
Range: 0.25-1.75mm (10-70 mils)
Best gap: 1.0mm (40 mils)
Output: 7.87V/mm (200mV/mil) ±12.5%/-20%
Error: <±0.06mm (±2.3 mils)
Probe resistance: 4.2±0.5Ω (1.0m length)
Cable specs: 0.220Ω/m (center), 0.066Ω/m (shield); 69.9pF/m capacitance
Temp range: -52°C to +177°C (-62°F to +351°F) (work & storage)

Installation Tips

Tighten: Finger-tight best; max 0.56N·m (5in·lb)
Bend: At least 25.4mm (1.0in) radius
Wiring: 0.2-1.5mm² (16-24 AWG); max 305m (1,000ft) from monitor
Target size: Min 8.9mm (0.35in); best 13mm (0.5in)

Compatibility

Works with Bently Nevada’s 3300 RAM probes and extension cables.

Package Details

New, factory-sealed. Includes probe, standard cable, and user manual.
Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
