Bently Nevada 3300 XL 11mm Reverse Mount Probe – 9m Vibration Check Tool
What It Is
A tough vibration monitor from Bently Nevada, made in the USA. Good for big machines like generators or pumps that need long sensor reach.
Key Details
Brand: Bently Nevada
Model: 330705-02-18-90-02-05
Type: 3300 XL 11mm Reverse Mount Probe
Main specs:
Length: 9.0m (29.5ft) – Only works with 9m Proximitor Sensors.
Connector: Small ClickLoc™ coaxial (Option 02).
Certificates: Passes many safety tests (Option 05).
Work Temp: -51°C to +177°C (-60°F to +351°F).
Store Temp: -52°C to +177°C (-62°F to +351°F).
DC Resistance: 8.5 ± 1.1 ohms (9m length).
Weight: 0.07kg – Light and easy to move.
What It’s Made Of
Tip: PPS plastic – Stays strong in high heat.
Case: 304 stainless steel – Stops rust and damage.
Cable: 75Ω triaxial, FEP insulation (1m, 5m, 9m options).
How to Install
Tighten: Use fingers. Max 0.565 N•m (5 in•lb).
Bend: At least 25.4mm (1.0in) radius (with/without armor).
Works With
Only 9m Proximitor Sensors. This pair gives the best results.
Tested Safe
Passes many industrial tests. Safe for rough jobs like factories.
Box Contents
Probe, install guide, 1 Viton® O-ring (helps seal pressure).
Warranty
1 year from buy date. Covers bad parts or making.
Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
